PowerConnect B-Series FCX Web Management Interface User Guide 111
53-1002268-01
Configuring the QOS profile
4
Configuring the QOS profile
Select Configure > QOS > Profile to configure the QOS profile. Click Apply to save your configuration
and click Reset to undo changes.
FIGURE 90 Configuring QOS profile
The QOS Profile display contains the following information.
Configuring the QOS bind
Select Configure > QOS > Bind to configure the QOS bind. Click Apply to save configuration and
click Reset to undo changes.
Show Mirror Port Displays the newly added mirror ports.
Add Enables you to add the ports.
Delete Enables you to delete the changes made.
Reset To undo your changes, click Reset.
Name Specifies the QoS profile name.
Committed Bandwith(%) This parameter can be any one of the following:
• Requested
• Calculated
Priority Displays the priority level from lowest to highest (0 - 7).
Bind Displays the QOS Bind screen.
