PowerConnect B-Series FCX Web Management Interface User Guide 125
53-1002268-01
Configuring RSTP
4
Configuring RSTP
Select Configure > RSTP, to enable RSTP feature in the PowerConnect B-Series FCX switch.
Earlier implementation of Rapid Spanning Tree Protocol (RSTP), which was 802.1W Draft 3 provides
only a subset of the IEEE 802.1W standard; whereas the 802.1W RSTP feature provides the full
standard. The implementation of the 802.1W Draft 3 is referred to as RSTP Draft3. RSTP Draft3 will
continue to be supported on Dell devices for backward compatibility. Users currently using RSTP
Draft 3 should migrate to 802.1W.
Cost The cost to the root bridge as advertised by the designated bridge that is connected
to this port. If the designated bridge is the root bridge itself, then the cost is 0. The
identity of the designated bridge is shown in the Design Bridge field.
Design Root The root bridge as recognized on this port. The value is the same as the root bridge
ID listed in the Root ID field.
Design Bridge The designated bridge to which this port is connected. The designated bridge is the
device that connects the network segment on the port to the root bridge.
Display Changes the unit ID by selecting a unit from the drop-down list and clicking Display.
