PowerConnect B-Series FCX Web Management Interface User Guide 11
53-1002268-01
Monitoring memory information
3
Monitoring memory information
Select Monitor > Memory, to view the memory information.
FIGURE 10 Monitoring the memory Information
The Memory Information window contains the following information.
Monitoring the front panel
A display of the front and rear panels of device in an IronStack allows you to view the modules in
each device and the ports within each module. Select Monitor > Front Panel to view the front and
rear panels for all stack units.
Unit ID Number of the unit within a stack (1-8).
Compressed Primary Code The compressed size, version, and image name for the Primary Code.
Compressed Secondary Code The compressed size, version, and image name for the Secondary Code.
Compressed Boot ROM Code The compressed size and version for the BootROM Code.
Code Flash Free Space The amount of available free space on the Flash memory.
Unit ID Number of the unit within a stack (1-8).
Total DRAM The size (in bytes) of DRAM.
Dynamic Memory The total number of bytes in dynamic memory, including the number of bytes that are
available (free, or unused), and the percentage of memory used.
