PowerConnect B-Series FCX Web Management Interface User Guide 133
53-1002268-01
Configuring static station
4
Configuring static station
Select Configure > Static Station to configure static station.
FIGURE 109 Configuring the static station
The static station display contains the following information.
Delete Enables you to delete the added port members.
Reset To undo your changes, click Reset.
Show Display the Trunk entries.
Add Trunk Allows you to add new ports.
MAC Address The MAC address of the device.
Vlan ID Enables you to select a Vlan ID. This Vlan ID field is disabled if no port was configured.
Port The port number.
QOS The QoS attribute specifies the priority of the incoming traffic based on any value between
0 (lowest priority) and 7 (highest priority). Default is 0.
Type Specifies the type of the device; host or route
Add Enables you to add the MAC Address.
Modify Enables you to modify the changes.
Delete Enables you to delete the changes made.
Reset To undo your changes, click Reset.
Show Displays the static station table entries.
