PowerConnect B-Series FCX Web Management Interface User Guide 17
53-1002268-01
Monitoring stack details
3
Monitoring stack details
Select Monitor > Stack > Details to view current detailed stack information.
FIGURE 15 Monitoring stack details
The Stack Details window contains the following information. You can also view Stack Port Status
and Stack Neighbors details in this window. Stack Details includes the following information.
Unit ID Defines the number of the unit within the stack.
Type Device model.
Role The role of this unit within the stack: Active, Standby, or Member.
MAC Address The MAC address of the device.
Priority The priority assigned to this unit.
State Local or Remote.
