66 PowerConnect B-Series FCX Web Management Interface User Guide
53-1002268-01
Configuring a standard ACL
4
FIGURE 49 Configuring system IP address
The system IP display contains the following information.
Configuring a standard ACL
Select Configure > System > Standard ACL to configure a standard ACL. Click Reset to undo
changes.
IP Address Configures the IP Address of the device.
Subnet Mask Configures the network mask for the IP Address.
Default Gateway Configures the IP address of a locally attached router (or a router attached to the Layer 2
Switch by bridges or other Layer 2 Switches).
