20 PowerConnect B-Series FCX Web Management Interface User Guide
53-1002268-01
Monitoring stack neighbors
3
Monitoring stack neighbors
Select Monitor > Stack > Neighbors to view current information about Stack Neighbors.
FIGURE 17 Monitoring stack neighbors
The Stack Neighbors contains the following information.
General Stacking Configuration Allows you to configure the general stacking configuration.
Configure Stack Priority Allows you to configure the stack unit priority.
Configure Stack Port Allows you to configure the stack port.
Configure Stack Modules Allows you to configure the stack modules.
Unit ID Identifies the number of the unit within the stack.
Stack-port1 Identifies the neighbor stack unit for stack-port1 for this unit ID.
Stack-port2 Identifies the neighbor stack unit for stack-port2 for this unit ID.
Topology Shows either Linear or Ring.
