PowerConnect B-Series FCX Web Management Interface User Guide 71
53-1002268-01
Configuring an IP access group
4
Configuring an IP access group
Select Configure > System > IP Access group to configure an IP access group.
FIGURE 53 Configuring a IP access group
The IP group contains the following information.
Source Range System
defined
Enables you to define the source range system.
Destination
Destination Port System
defined
Enables you to define the destination port system.
Destination Range
System defined
Enables you to define the destination range system.
Port The port attached to the device for which the entry was made.
Direction Specifies the direction you want the filtering to take place.
ACL Number Displays the ACL number.
Add Allows you to add the port number.
