Delta ASD-A2R-1B43 Series User Manual

Chapter 3 Wiring ASDA-A2R Series
3-64 Revision December. 2014
3.11.3 Signal Converter Box
If you desire to connect Delta’s servo drive to other brands of motor, ASD-IF-EN0A20
signal converter box is a great choice for you. It does not require external power-supply,
driver or any complicated setting process.
Features and Functions:
 It can convert the square wave and sine wave to the communication signals which is
exclusive use for Delta’s servo system. It can be controlled by Delta’s servo drive.
 After the signal is converted to high resolution signal, it can dramatically enhance the
motor speed, provide precise position and control the speed limit so as to satisfy the
demand of speed and precision.
It can fine-cut the sinusoid analog signal up to 2048 times, e.g. 20 m

pitch of
single-phase sinusoid analog signal is outputted to linear scale, which can up to the
resolution of
nmm 10
2048
20
 
via transition card.
 The original signal can be delivered to over 20 m without attenuation, which could
ensure communication quality.
 Through the interpolation of sine wave signal, it could improve the resolution and avoid
the limit of frequency so as to satisfy the demand of high-precision and high-speed for
linear motor.
Installation
The product should be kept in the shipping carton before installation. In order to retain the
warranty coverage, the product should be stored properly when it is not used for a period
of time. Some storage suggestions are:
 Store in a clean and dry location.
 Store within an ambient temperature range of -20°C to +65°C (-4°F~149°F).
 Store within a relative humidity range of 0% to 90% and non-condensing.
 Do not store in a place subject to corrosive gases and liquids.
 Correctly packaged and place on a solid surface.
 Do not mount the production adjacent to heat-radiating elements, water, vapour, dust
and oily dirt. The location should free from corrosive gases, liquids, airborne dust or
metallic particles and no vibration and interference.
Model Name Explanation
ASD - IF – EN 0A 20
(1) (2) (3) (4) (5)
(1) Product ASD: AC Servo Drive
(2) Product Name IF: Interface
(3) Module Type EN: Encoder
(4) Version Number 0A: Version Number
(5) Specification of
Connection Port
20: Connect to 20pin
connector
