Delta ASD-A2R-1B43 Series User Manual

Chapter 1 Inspection and Model Explanation ASDA-A2R Series
Revision December, 2014
1-13
1.5 ECML Series Servo Motor
Motor power cable
It contains 4 core cables, which are for
U, V, W and ground wire. It connects to
output port of the servo drive and
grounding terminal.
It contains 7 core cables, which are for
Hall Sensor and NTC thermistor. It
connects to CN2 or CN5. Please refer
to Ch3.1 for wiring method.
Encoder cable
