Chapter 2 InstallationASDA-A2R Series
2-4 Revision December, 2014
2.5 Specification of Circuit Breaker and Fuse
Caution: Please use the fuse and circuit breaker that is recognized by UL/CSA.
Servo Drive Model Circuit breaker Fuse (Class T)
Operation Mode General General
ASD-A2R-0121- 5A 5A
ASD-A2R-0221- 5A 5A
ASD-A2R-0421- 10A 10A
ASD-A2R-0721- 10A 20A
ASD-A2R-1021- 15A 25A
ASD-A2R-1521- 20A 40A
ASD-A2R-2023- 30A 50A
ASD-A2R-3023- 30A 70A
NOTE
If the servo drive equips with earth leakage circuit breaker for avoiding
electric leakage, please choose the current sensitivity which is over
200mA and can continue up to 0.1 seconds.
