Transport Layer Security (TLS) TLS AT commands
Digi XBee3 Cellular LTE-M/NB-IoT Global Smart Modem User Guide
152
TLS AT commands
Note For NB-IoT, TCP support is dependent on the network. Contact your network provider for
details.
These AT commands, when used together, let you interact with TLSfeatures: ATFS (File System), TL
(SSL/TLS Protocol Version), IP (IP Protocol), $0 (SSL/TLS Profile 0), $1 (SSL/TLS Profile 1), and $2
(SSL/TLS Profile 2). The format of the $ commands is:
AT$<num>[<ca_cert>];[<client_cert>];[<client_key>]
Where:
n num: Profile index. Index zero is used for Transparent mode connections and TLS connections
using Transmit (TX) Request: IPv4 - 0x20.
n ca_cert: (optional) Filename of a file in the certs/ directory. Indicates the certificate identifying
a trusted root certificate authority (CA) to use in validating servers. If ca_cert is empty the
server certificate will not be authenticated. This must be a single root CA certificate. The
modules do not allow a non-self signed certificate to work, so intermediate CAs are not
enough.
Note This module will only work with the originating end of chain Root CA, so you will need to use that
one. For example, with Amazon web services ATS endpoints Digi recommends that you use the
Starfield Services Root Certificate from https://www.amazontrust.com/repository/. The intermediate
"root CAs" from Amazon will not work. You will need the actual end of chain certificate.
n client_cert: (optional) Filename of a file in the certs/ directory. Indicates the certificate
presented to servers when requested for client authentication. If client_cert is empty no
certificate is presented to the server should it request one. This may result in mutual
authentication failure.
n client_key: (optional) Filename of a file in the certs/ directory. Indicates the private key
matching the public key contained in client_cert. This should be a secure file uploaded with
ATFS XPUTfilename. This should always be provided if client_cert is provided and match the
certificate or client authentication will fail.
The default value is ";;". This default value preserves the legacy behavior by allowing the creation of
encrypted connections that are confidential but not authenticated.
To specify a key stored outside of certs/, you can either use a relative path, for example ../server.pem
or an absolute path starting with /flash, for example /flash/server.pem. Both examples refer to the
same file.
It is not an error at configuration time to name a file that does not yet exist. An error is generated if
an attempt to create a TLS connection is made with improper settings.
n Files specified should all be in PEM format, not DER.
n Upload private keys securely with ATFS XPUTfilename.
n Certificates can be uploaded with ATFS PUTfilename as they are not sensitive. It is not
possible to use ATFS GETfilename to GETthem if they have been securely uploaded.
To authenticate a server not participating in a public key infrastructure (PKI) using CAs, the server
must present a self-signed certificate. That certificate can be used in the ca_cert field to authenticate
that single server.
There are effectively three levels of authentication provided depending on the parameters provided
