API frames Modem Status - 0x8A
Digi XBee3 Cellular LTE-M/NB-IoT Global Smart Modem User Guide
222
Modem Status - 0x8A
Description
Cellular component status messages are sent from the device in response to specific conditions.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
format.
Field name Field value Data type Description
Frame type 0x8A Byte
Status ## Byte 0 = Hardware reset or power up
1 = Watchdog timer reset
2 = Registered with cellular network
3 = Unregistered with cellular network
0x0E = Remote Manager connected
0x0F = Remote Manager disconnected
0x32 = BLE Connect
0x33 = BLE Disconnect
0x34 = Bandmask configuration failed
Note The BLEConnect and BLE Disconnect events are reported over the UART/SPI interface in API
mode when a valid Bluetooth connection has been made and API mode has been unlocked, and also
when an unlocked connection disconnects.
