Get started with the XBee Smart Modem Development Kit Connect the hardware
Digi XBee3 Cellular LTE-M/NB-IoT Global Smart Modem User Guide
19
Connect the hardware
1. The XBee Smart Modem should already be plugged into the XBIB-U-DEV board.
2. If a SIM card is included with the kit, the card is inserted into the XBee Smart Modem. If a SIM
card is not included, install the SIMcard into the XBee Smart Modem before attaching the XBee
device to the board.
Note NB-IoT kits (Digi product number XK3-C-N1-UT-E) do not include a SIM card. Contact your
NB-IoT mobile carrier provider to obtain a SIM card and service. See Acquire a SIM card.
WARNING! Never insert or remove the SIM card while the device is powered!
3. Attach the XBee device to the board.
4. Connect the antennas.
a. Connect the cellular antenna.
b. Connect the BLE antenna if you are using BLE functionality. If you are not, you do
not have to connect the BLEantenna.
