Ducati 999 User Manual

32
E
2
1 3
fig. 26
Gear change pedal adjustment (fig. 26)
Gear change pedal position relative to the footpeg may
be adjusted to suit rider preferences.
There are three different adjustments available:
Approximate adjustment of pedal position
Fit a wrench into the socket (1) to lock out removable
linkage rotation and slacken the locknut (3). Release and
remove the screw (2) and adjust the linkage axially so as
to set the gear change pedal in the desired position. The
linkage has four positions determined by the axis of the
screw (2). When finished, tighten the screw (2) and the
locknut (3).
Fine adjustment
Fit a wrench into the socket (1) to lock out removable
linkage rotation and slacken the locknut (3). Rotate the
linkage working the socket (1) so as to set pedal in the
desired position. When finished, tighten the locknut (3).
Combined adjustment
Both adjustment techniques may be used together. Make
sure to tighten locknut (3) and screw (2) when finished.

Ducati 999 Specifications

General

Compression Ratio	11.4:1
Transmission	6-speed
Fuel Tank Capacity	15.5 l (4.1 US gal)
Rear Suspension	Progressive linkage with fully adjustable Showa monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Tire Front	120/70 ZR 17
Tire Rear	190/50 ZR 17
Engine Type	L-Twin cylinder, 4 valves per cylinder Desmodromic
Bore x Stroke	100 mm x 63.5 mm
Power	104 kW (141 hp) @ 9750 rpm
Torque	110 Nm (81.4 lb-ft) @ 8000 rpm
Front Suspension	Showa 43 mm upside-down fork, fully adjustable
