Ducati 999 User Manual

71
E
1
HI
LO
LO
USA
HI
USA
3
2
Changing the high and low beam bulbs
Before replacing a burnt-out bulb, make sure that the
new one complies with voltage and wattage as specified
on page 92, “Electric System”, for that lighting device.
Always check for new bulb proper operation before
refitting removed parts.
Figure 65 shows the position of the low beam (LO), high
beam (HI) and parking light (1) bulbs.
Important
In the USA version, the position of the high and low
beam bulbs is reversed.
Headlamp
Remove the instrument panel (2) from retainig rubber
elements (see page 58) to give access to the upper bulb.
Rotate the locking ring nut (3) of the upper bulb body
anti-clockwise and extract the burnt-out bulb. Replace
with a bulb of equal rating.
On refitting, rotate the locking ring nut (3) clockwise to
secure the bulb in place.
To gain access to the lower bulb, remove the headlamp
fairing as described in paragraph “Removing the fairings”
on page 56 and unscrew the screws (5) to release the
bottom cover (4) of the headlamp support. Change the
bulb as described for upper bulb removal.
fig. 65
fig. 66

Ducati 999 Specifications

General

Compression Ratio	11.4:1
Transmission	6-speed
Fuel Tank Capacity	15.5 l (4.1 US gal)
Rear Suspension	Progressive linkage with fully adjustable Showa monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Tire Front	120/70 ZR 17
Tire Rear	190/50 ZR 17
Engine Type	L-Twin cylinder, 4 valves per cylinder Desmodromic
Bore x Stroke	100 mm x 63.5 mm
Power	104 kW (141 hp) @ 9750 rpm
Torque	110 Nm (81.4 lb-ft) @ 8000 rpm
Front Suspension	Showa 43 mm upside-down fork, fully adjustable
