Ducati 999 User Manual

77
E
The vertical position of the headlamp is set by means of
the adjusting knobs (1, fig. 74) on the left side of the
headlamp. Rotate the knobs clockwise to lower the
beam or anti-clockwise to raise it.
Note
To gain access to the lower knob, you must first
remove the headlamp fairing as described on page 58.
Rear view mirror adjustment (fig. 75)
The rear view mirror is adjusted manually by pressing at
position (A).
A
fig. 75
DOWN
UP
1
fig. 74

Ducati 999 Specifications

General

Compression Ratio	11.4:1
Transmission	6-speed
Fuel Tank Capacity	15.5 l (4.1 US gal)
Rear Suspension	Progressive linkage with fully adjustable Showa monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Tire Front	120/70 ZR 17
Tire Rear	190/50 ZR 17
Engine Type	L-Twin cylinder, 4 valves per cylinder Desmodromic
Bore x Stroke	100 mm x 63.5 mm
Power	104 kW (141 hp) @ 9750 rpm
Torque	110 Nm (81.4 lb-ft) @ 8000 rpm
Front Suspension	Showa 43 mm upside-down fork, fully adjustable
