FloBoss 107 Instruction Manual
5-16 Communications Revised June-2017
The module has removable terminal blocks for convenient wiring and
servicing. The terminal blocks can accommodate size 16 to 24 American
Wire Gauge (AWG). The module uses a standard “tip and ring” PSTN
wiring schema.
Figure 5-16. Dial-Up Modem Module
5.9 Network Radio Module (NRM)
The Network Radio Module (NRM) is an integral part of the Distributed
RTU Network and allows the FB107 to communicate wirelessly. It has
the ability to broadcast and detect information from other RTUs for easier
and faster interconnection and communication setup.
The NRM provides a wireless solution of transferring data from RTU to
another RTU within the Distributed RTU Network (DRN). The data can
be any type of information that the RTU has in its database, such as I/O,
soft points, or other information.
