FloBoss 107 Instruction Manual
1-2 General Information Revised June-2017
This chapter provides an overview of the FB107 and its components.
1.1 Scope of Manual
This manual contains the following chapters:
Chapter 1
General Information
Provides an overview of the hardware and firmware
for the FB107 base unit and the expansion rack.
Chapter 2
Installation and Use
Provides information on installation, tools, wiring,
and other essential elements of the FB107.
Chapter 3
Power Connections
Provides information on determining power
requirements for the FB107.
Chapter 4
Inputs and Outputs
Provides information for the input/output (I/O)
modules, CPU I/O assembly, and the RTD input.
Chapter 5
Communications
Provides information for the built-in communication
ports and the optional communication modules.
Chapter 6
Sensors and
Transducers
Provides information on the optional Multi-Variable
Sensor (MVS), Dual Variable Sensor (DVS), and
Pulse Input modules.
Chapter 7
Troubleshooting
Provides information on diagnosing and correcting
problems.
Glossary
Provides definitions of acronyms and terms.
Index
Provides an alphabetic listing of items and topics
contained in this manual.
1.2 FloBoss 107 Overview
A 32-bit microprocessor-based electronic flow computer, the FB107
electronically measures, monitors, and manages flow. This economical
flow computer reliably and accurately performs flow calculations,
temperature measurements, and data archival.
Note: You configure the functionality of the FB107 and monitor its
operation using a personal computer (PC) running ROCLINK 800
(“ROCLINK 800”) software.
The FB107 can measure up to four meter runs through a variety of
devices, such as an orifice plate, turbine meter, or other pulse-generating
devices. Meter inputs may also use analog transmitters. For multiple
differential pressure-run applications, you can add an optional Multiple-
Variable Sensor (MVS) module to provide an interface to remote MVS
transmitters.
The FB107 performs minute, hourly, daily, and minimum / maximum
historical data archival for standard history and a configurable time
interval archival for extended history. As the electronic solution to
replace traditional paper charting, the FB107 records the corrected flow
for differential or pulse counts and stores the data.
The FB107 computes flow for both volume and energy. It provides on-
site functionality and supports remote monitoring, measurement, data
archival, communications, and control. It stores the results of the flow
