FloBoss 107 Instruction Manual
Revised June-2017 Installation and Use 2-13
3. Remove the battery by gently prying the battery from its terminals.
4. Replace the battery by placing the battery positive-side up and gently
pressing it into place.
5. Slide the Memory Backup cover back over the battery.
6. Restore power to the FB107.
Note: The super capacitor is not field-replaceable.
2.4 Central Processor Unit (CPU)
The FB107 base unit has four slots. Slot 0 is reserved for the CPU
module. The CPU provides connections to the field wiring and surge and
static discharge protection for the field wiring. Electronics include the
RTD, comms, and power.
The CPU contains the firmware, the three built-in communication ports
and LEDs, a reset (RST) switch, RTD input, and a power LED indicating
system integrity.
The internal super-cap backup battery provides backup of data and the
real-time clock when the main power is not connected.
