FloBoss 107 Instruction Manual
Revised June-2017 Troubleshooting 7-5
7.3.3 Inputs/Outputs
If you are experiencing troubles with an I/O point (analog input, analog
output, discrete input, discrete output, pulse input, or RTD):
 Ensure that power is applied to the FB107.
 Verify the wiring connections at PWR+ and PWR.
 Verify the wiring connections at the power source.
 Verify how the channel is configured using ROCLINK 800 software
(Configure > I/O).
 If the configuration looks correct, then simulate an input (within the
range of the input) or force the production of an output using
ROCLINK 800 software:
AI +
AO —
 If I/O does functions correctly, determine if the problem is with the
field device or the loop power:
AI +
Loop
AI —
Device
 If the types of I/O available for configuration do not match the type of
I/O wired to the terminations, check the I/O Setup screen (refer to
Chapter 4, Inputs and Outputs).
 If an input channel is in question, you may be able to use one of the
outputs (known to be in working order) to simulate the required input.
Likewise, if an output channel is in question, you may able to connect
it to a working input channel and check the results.
Notes:
 FB107 modules do not contain any user-serviceable parts.
 You must perform a power restart to allow ROCLINK 800 to identify
the module.
