FloBoss 107 Instruction Manual
1-22 General Information Revised June-2017
1.6 Product Electronics
This section describes the FB107 electronic components.
1.6.1 Real-Time Clock
The real-time clock provides the FB107 with the time of day, month,
year, and day of the week, as well as real-time stamping of the database
values. The real-time clock automatically switches to backup power when
the FB107 loses primary input power. Backup power for the real-time
clock is adequate for a period in excess of one-year with no power
applied to the FB107.
The internal super-cap provides backup for the data and the real-time
clock when the main power is not connected. The super-cap has a one-
year minimum backup life with the battery installed and no power applied
to the FB107.
Note: The real-time clock uses the super-cap to keep the current time
when you replace the lithium battery.
1.6.2 Diagnostic Monitoring
The electronics board has five diagnostic inputs incorporated into the
circuitry for monitoring system integrity. Access these analog inputs
using the I/O function of ROCLINK 800 software (Configure > I/O).
Refer to Table 1-1.
Table 1-1. System Analog Inputs
System AI
Point Number
Function
Point of
Origination
Normal Range
E1
Logic voltage
CPU
3.0 to 3.6
E2
Battery voltage
Backplane voltage
input connector P1
11.25 to 16 Volts dc
8 to 30 Volts dc
E3
Charge in voltage
CPU power input
0 to 18 Volts dc
8 to 30 Volts dc
E4
System milliAmps
CPU power input
E5
Board temperature
CPU
40 to 85C (40 to 185F)
For information on configuring alarms and System AI points, refer to
Chapter 7 in the ROCLINK 800 Configuration Software User Manual
(for FloBoss 107) (Form A6217).
1.6.3 Automatic Self Tests
The FB107 becomes active when input power with the proper polarity
and startup voltage (typically set greater than 8.0 volts) is applied to the
PWR+ / PWR connector (provided the power input fusing/protection is
