FloBoss 107 Instruction Manual
Revised June-2017 Troubleshooting 7-1
Chapter 7 – Troubleshooting
In This Chapter
7.1 General Guidelines ............................................................................. 7-1
7.2 Graphical User Interface (GUI) ........................................................... 7-2
7.3 Checklists ........................................................................................... 7-4
7.3.1 LEDs ...................................................................................... 7-4
7.3.2 Serial Communications ......................................................... 7-4
7.3.3 Inputs/Outputs ....................................................................... 7-5
7.3.4 Preserving Configuration and Log Data ................................ 7-6
7.3.5 ROCLINK 800 Configuration Software .................................. 7-6
7.3.6 Powering Up .......................................................................... 7-7
7.3.7 Multi-Variable Sensor (MVS) ................................................. 7-7
7.3.8 Resistance Temperature Detector (RTD) ............................. 7-7
7.3.9 IEC 62591 Module ................................................................. 7-8
7.3.10 Network Radio Module (NRM) .............................................. 7-8
7.4 Procedures ......................................................................................... 7-8
7.4.1 Resetting the FB107 .............................................................. 7-9
7.4.2 Restarting and Reconfiguring the FB107 .............................. 7-9
7.4.3 Troubleshooting Analog Inputs............................................ 7-10
7.4.4 Troubleshooting Analog Outputs ......................................... 7-11
7.4.5 Troubleshooting Discrete Inputs ......................................... 7-12
7.4.6 Troubleshooting Discrete Outputs ....................................... 7-12
7.4.7 Troubleshooting Pulse Inputs .............................................. 7-13
7.4.8 Troubleshooting RTD Inputs ............................................... 7-13
7.4.9 Troubleshooting the Multi-Variable Sensor (MVS) .............. 7-15
7.4.10 Troubleshooting the Enhanced Comm Module (ECM) ....... 7-16
7.4.11 Troubleshooting the Dual Variable Sensor (DVS)............... 7-16
7.4.12 Troubleshooting the Pressure Module (PIM) ...................... 7-17
7.4.13 Troubleshooting AI/DI .......................................................... 7-18
7.4.14 Troubleshooting the Discrete Output Relay (DOR) ............. 7-18
This chapter provides generalized guidelines for troubleshooting the
FB107. Use the procedures in this chapter before you remove power, after
you restore power, or if you disassemble the FB107.
The following tools are required for troubleshooting:
 A personal computer (PC) running Windows
®
2000 (with Service Pack
2), Windows XP, or Windows Vista.
 ROCLINK 800 software.
 Flat-head (size 1/10 inch) screwdriver.
 Philips (size 0) screwdriver.
7.1 General Guidelines
When you are attempting to diagnose a problem with a FB107:
 Write down what steps you have taken.
