FloBoss 107 Instruction Manual
Revised June-2017 Inputs and Outputs 4-1
Chapter 4 – Inputs and Outputs
In This Chapter
4.1 I/O Description .................................................................................... 4-1
4.2 Installing a Module ............................................................................. 4-5
4.3 Removing a Module ........................................................................... 4-6
4.4 Wiring a Module.................................................................................. 4-7
4.5 Selecting the Type of I/O .................................................................... 4-7
4.6 Analog Inputs (AI) ............................................................................... 4-9
4.6.1 Wiring the Analog Inputs ....................................................... 4-9
4.7 8-Point Analog Input/Digital Input (AI/DI) Module ............................ 4-11
4.7.1 Wiring the 8-Point AI/DI ....................................................... 4-11
4.8 Analog Outputs (AO) ........................................................................ 4-13
4.8.1 Wiring the Analog Outputs .................................................. 4-13
4.9 Discrete Inputs (DI) .......................................................................... 4-14
4.9.1 Wiring the Discrete Inputs ................................................... 4-15
4.10 Discrete Outputs (DO) ...................................................................... 4-15
4.10.1 Wiring the Discrete Outputs ................................................ 4-16
4.11 Discrete Outputs Relay (DOR) Module ............................................ 4-17
4.11.1 Wiring the Discrete Output Relays ...................................... 4-18
4.12 Pulse Inputs (PI) ............................................................................... 4-19
4.12.1 Wiring the Pulse Inputs ....................................................... 4-19
4.13 Application (APP 485) Module ......................................................... 4-20
4.13.1 Wiring the Application Module ............................................. 4-20
4.14 Resistance Temperature Detector (RTD) Input ............................... 4-22
4.14.1 Wiring the RTD Input ........................................................... 4-22
4.15 6-Point AO/DO Module ..................................................................... 4-23
4.15.1 Wiring the 6-Point AO/DO Module ...................................... 4-24
4.16 HART
®
Module ................................................................................. 4-24
4.16.1 Wiring the HART Module ..................................................... 4-25
4.17 Resistance Temperature Detector (RTD) Module ............................ 4-26
4.17.1 Wiring the RTD Module ....................................................... 4-26
4.18 IEC 62591 Module ............................................................................ 4-27
4.18.1 Wiring the IEC 62591 Module ............................................. 4-28
4.19 Related Product Data Sheets ........................................................... 4-28
This chapter describes the input/output (I/O) termination points available
on the CPU module’s optional I/O assembly and the I/O modules. I/O
points provide additional inputs and outputs for implementing expanded
monitoring and control applications. This chapter also describes the
resistance thermal device (RTD) input on the CPU.
Note: You can place an I/O module in any slot (1 through 7) in the
FB107. When you install a non-I/O module in slot 1, you can
install an I/O module in slot 7 of the expansion rack.
4.1 I/O Description
The I/O options use the microprocessor to monitor, control, and acquire
data from external devices connected to the I/O channels. The I/O
