FloBoss 107 Inst
ruction M
anua
l
4-
12
Inputs and Outputs
Revised June-20
17
DI channel, you can use ROCLINK 800 to configure the channel as
necessary.
+
-
OPEN DRAIN TYPE
OR
OPEN COLLECTOR DEVICE
EXTERNALLY POWERED
+
-
CONTACT-CLOSURE DEVICE
EXTERNALLY POWERED
DISCRETE DEVICE
DISCRETE DEVICE
Figure 4-8. DI Wiring
INTERNALLY
POWERED
DEVICE
ANALOG
Figure 4-9. AI Wiring (Internal Power)
69
71
