Epson VT6L User Manual

Maintenance 8. Cable
164 VT Rev.1
8.2 Insert or Pull out of Power Cable
Name
Quantity
Note
Tools
Cross-point screwdriver (No. 2)
1
For cross-recessed screw
Power Cable
Pull out
(1)
Turn OFF
the Manipulator.
(2)
Remove
the power cable cover.
Reference: Maintenance 7.6 Power Cable Cover
(3)
Remove the power cable clamp.
(4)
Disconnect
the power cable connector.
When removing the power cable connector, pull it out with pushing latches on
both
sides of
the connector.
Power Cable
Insertion
(1)
Connect
the power cable connector.
(2)
Mount
the power cable clamp.
(
3)
M
ount the power cable cover.
Reference: Maintenance 7.6 Power Cable Cover

