Setup & Operation 9. LAN (Ethernet Communication) Port
78 VT Rev.1
When the Manipulator and the development PC are connected via the Ethernet, the
Manipulator IP address can also be changed. However, Manipulator and the
development PC do not connect automatically after rebooting the Manipulator at Ethernet
connection.
9.4 Connection of Development PC and Manipulator with Ethernet
Connection between the development PC and the Manipulator is shown below.
(1) Connect the development PC and the Manipulator using the Ethernet cable.
(2) Turn on the Manipulator.
(3) Start EPSON RC+ 7.0.
(4) Display the [PC to Controller Communication] dialog from [Setup] in EPSON RC+
7.0 menu.
(5) Click the <Add> button.
(6) Connection “No.2” is added. Set the following and click the <Apply> button.
Name : Valid value to identify the Manipulator to connect
IP Address : IP address for Manipulator to connect
To Next Page
