FS TAP Series User Manual

TAP Series Switch Command Line Reference
194
Related Commands
show radius-server
14.37 radius-server key
Use this command to set the shared encryption key of RADIUS server.
Use the no form of this command to delete the configuration.
Command Syntax
radius-server key ( 8 |) STRING
no radius-server timeout
8
Specifies a hidden password will follow
STRING
RADIUS server key-string
Command Mode
Global Configuration
Default
None
Usage
Use this command to set the shared encryption key in a switch. Shared encryption key is the
foundation of communicate between switch and server. You need set a same shared
encryption string in authentication server and switch.
Examples
This example shows how to set the radius-server key:
Switch(config)# radius-server key 123456
This example shows how to unset radius-server key:
Switch(config-if)# no radius-server key
