Printing Basics 133
îš„ Automatic Document Feeder (ADF) Guidelines
The ADF can accommodate the paper of the following sizes:
• Width: 148–215.9 mm (5.83–8.50 inches)
• Length: 210–355.6 mm (8.27–14.00 inches)
The supported paper weight ranges from 60 to 105 gsm.
Follow the guidelines below when loading source documents into the ADF:
• Load documents face up so that the top of the document enters the printer first.
• Place only loose sheets of paper in the ADF.
• Adjust the document guides so that they fit against the documents.
• Insert paper in the document feeder tray only when the ink on the paper is completely dry.
• Do not load documents above the MAX fill line. You can load up to 50 sheets of 64 gsm
documents.
NOTE:
• You cannot load the following documents on the ADF. Be sure to place them on the document glass.
Curled documents Pre-punched paper
Lightweight documents Folded, creased or torn documents
Cut and paste documents Carbon paper
