190-02246-10 GI 275 Part 23 AML STC Installation Manual
Rev. 11 Page 6-3

HSI Ground Check (complete all applicable checks)
GPS
NAV
Traffic
Weather
Databases
Section 6.3.1
Section 6.3.2
Section 6.3.3
Section 6.3.5
Section 6.3.10

MFD Ground Check (complete all applicable checks)
GPS
NAV
Traffic
Weather
Stormscope
Radar Altimeter
Transponder Control
Databases
MFD-Specific
OAT
Section 6.3.1
Section 6.3.2
Section 6.3.3
Section 6.3.5
Section 6.3.6
Section 6.3.7
Section 6.3.8
Section 6.3.10
Section 6.5.2
Section 6.5.2.1

EIS Ground Check (complete all applicable checks)
EIS-Specific
Temperature sensor
EIS gauge layout and markings
Manifold pressure
Oil pressure
Fuel pressure
Tachometer
Fuel quantity
Fuel flow
Shunt/Voltage
(OAT) EIS Check
EIS engine run-up
Section 6.5.3
Section 6.5.3.1
Section 6.5.3.2
Section 6.5.3.2.1
Section 6.5.3.2.2
Section 6.5.3.2.3
Section 6.5.3.2.4
Section 6.5.3.2.5
Section 6.5.3.2.6
Section 6.5.3.2.7
Section 6.5.3.2.8
Section 6.5.3.3

Standby Indicator Check Section 6.5.4

AHRS Calibration Checks
Magnetometer calibration
Compass swing
Engine run-up vibration
Magnetometer interference
Site evaluation
Section 6.4.1
Section 6.4.2
Section 6.4.3
Section 6.4.4
Section 6.4.5

Autopilot Ground Check (complete all applicable checks)
Autopilot engagement
Flight director
Heading and Course error
VOR /ILS/GS
GPS roll steering
Section 6.3.9.1
Section 6.3.9.2
Section 6.3.9.3
Section 6.3.9.4
Section 6.3.9.5

Placards, Switches, and Labels Section 6.6
