Chapter 3: Programming
146 EST iO64 and iO500 Technical Reference Manual
AC voltage programming
AC Voltage is used to select the rated voltage of the mains supply
connected to the control panel. The possible values are 110, 115,
120, 220, 230, and 240 VAC.
Note: Use 110, 115, and 120 only on 120 VAC control panel models.
Use 220, 230, and 240 only on 230 VAC control panel models.
Panel Configuration
GWY 000.000.000.000
Lock Rmt Read Yes<>
AC Voltage 120<>
⇩
To program AC voltage:
1. Access the panel configuration options menu. See "Panel
configuration options."
2. Choose AC Voltage.
3. Select either 110, 115, 120, 220, 230, or 240.
4. Program other panel configuration options or choose Save if
you're finished.
5. Continue programming your system or press Menu to exit menu
mode.
Panel Configuration
Lock Rmt Read Yes<>
AC Voltage 120<>
Save
