GE EST iO500 User Manual

Appendix B: Worksheets
EST iO64 and iO500 Technical Reference Manual 227
Panel configuration worksheet
The panel configuration worksheet is used to document the
configuration and settings of your system programming options.
Note: For default settings, refer to “Factory default settings.”
NAC
Class ☐ Class B ☐ Class A
Type
☐ Genesis with audible
silence
☐ Continuous
(silenceable)
☐ Temporal
(nonsilenceable)
☐ Genesis with
audible/visible silence
☐ Continuous
(nonsilenceable)
☐ Temporal (silenceable)
☐ Genesis (nonsilenceable) ☐ Coder - continuous ☐ Coder - temporal
☐ Coder - 120 SPM ☐ Coder - basic
Label (up to
40 characters)
Correlation groups
Event notification:
Trouble
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Disable
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Test
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (4-digit coded output)
CID
Annunciator class ☐ Class B ☐ Class A
Annunciator
Type ☐ Off ☐ LCD-C ☐ LCD ☐ LED ☐ Graphic
Expanders ☐ None ☐ 1 or 2
Label (up to
40 characters)
