GE Revolution CT User Manual

•
All jobs
•
All PPS jobs (only for sites with PPS, HIS or RIS systems)
•
All Network jobs
•
All Archive jobs
•
Network push
•
Network retrieve
•
Archive record (Not Applicable)
•
Archive restore (Not Applicable)
•
Remote archive
Job Queue
The Job Queue area displays the list of registered jobs as defined from the Show All Jobs
menu.
Click and drag the edges of each title in the menu bar to expand or contract the field.
Click a title in the menu bar to sort the list.
The job status types include:
•
Paused — indicates that stops the progress of a transmission
•
Failed
•
Running — indicates the job is active
Illustration 17: Queue list
Completed Jobs
The Completed Jobs area displays when a successful transfer is completed the job is listed.
The most recent job is listed at the top of the list.
Click [Clear] to remove all jobs from the Completed Jobs list.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
520 3 Job Management Screen

GE Revolution CT Specifications

General

Detector Coverage	Up to 160 mm
Gantry Tilt	± 30 degrees
Spatial Resolution	Up to 0.23 mm
Scan Range	Up to 200 cm
X-ray Tube Current	Up to 800 mA
Type	Computed Tomography (CT) Scanner
Rotation Speed	0.28 seconds per rotation
Tube Voltage	80 kV to 140 kV
Number of Detector Rows	256
Power Requirements	480 VAC, 3-phase
Detector Rows	256
Coverage	160mm
