HEIDENHAIN MANUALplus 4110 Tool Measurement 5.1
Preparing for tool measurement
Tool measurement
The tool setting dimensions are determined relative to the measured tool T1.
 First step: Determine the workpiece datum to set a “measuring diameter”
 Further steps: Determine the setting dimensions of the tools by touching the workpiece.
Prepare the machine
Entering the machine data
 Clamp a workpiece
 Clamp tool T1
 Call the main menu:
Press the Menu key
 Select machine-data entry:
Press the Set S, F, and T
menu key
