Huawei FusionServer G5500 User Manual

The LSI SAS3008 supports RAID 0 and 1.
The LSI SAS3108 supports RAID 0, 1, 5, 6, 10, 50, and 60.
For details, see the HUAWEI V2&V3 Server RAID Controller Card User Guide.
5.4.6 Configuring the BIOS
This topic describes how to configure the basic input/output system (BIOS) for the G560.
Scenarios
Set the BIOS for the G560 in remote control mode.
BIOS settings include:
l Server boot priority
l NIC Preboot Execution Environment (PXE) priority
l BIOS password
For other settings, see the HUAWEI Server Grantley Platform BIOS Parameter Reference.
NOTE
l The password complexity check function is enabled by default.
l A simple password is easy to crack, which makes the system vulnerable. You are advised to use a
password that meets complexity requirements or to enable the password complexity check function.
l To ensure system security, change your initial password at your first login and change the password
periodically.
Prerequisites
Conditions
The G560 is powered on.
Data
No data preparation is required for this operation.
Workflow
Figure 5-18 shows the process for configuring the BIOS.
FusionServer G5500 Server
User Guide
5 Configuring the G5500
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
94

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
