Huawei FusionServer G5500 User Manual

6.3.2 GPU Card and GPU Filler Module
Installing a GPU Card
Step 1 Remove the GP608. For details, see 3.4 Removing the GP608.
Step 2 Place the GP608 on the ESD floor.
Step 3 Remove the cover. For details, see 3.7 Cover.
Step 4 Take a spare GPU card out of its ESD bag.
Step 5 Install the GPU card bracket.
NOTE
GPU cards are provided by other vendors and their card brackets are incompatible with the GP608. An Atlas
GPU card bracket must be installed on these cards. Otherwise, the GPU card cannot be installed.
Step 6 Determine the location for installing the GPU card. Figure 6-20 shows the locations of GPU
cards.
Figure 6-20 Locations of GPU cards
Step 7 Align the GPU card with the slot, and insert the GPU card into the slot. See (1) in Figure
6-21.
FusionServer G5500 Server
User Guide
6 Optional Part Installation
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
140

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
