Step Action
Install an OS. Install an OS for the G530 V2.
NOTE
Use the Huawei Server Compatibility Checker to check OSs
supported by the G530 V2
Documents
Refer to the following documents during G530 V2 configuration:
l FusionServer G5500 Server 1.0.0 iBMC User Guide
l HUAWEI V5 Server RAID Controller Card User Guide
l HUAWEI Server Grantley Platform BIOS Parameter Reference
l HUAWEI Server OS Installation Guide
l Huawei Servers Troubleshooting
5.5.1 Logging In to the iBMC WebUI
This document takes the Internet Explorer 11 as an example to describe how to log in to the
iBMC WebUI.
Context
l Prepare the following data before logging in to the iBMC WebUI:
– IP address of the iBMC management network port
NOTE
The G5500 supports two G530 V2 compute modules to be installed in the lower two slots
G530 V2-1 and G530 V2-2 from left to right. The default iBMC IP address of G530 V2-1 is
10.10.1.101, and that of G530 V2-2 is 10.10.1.102.
– User name and password of the iBMC management network port
NOTE
The default iBMC user name is Administrator, and the default password is Admin@9000.
l The system allows a maximum of four users to log in concurrently.
l By default, the system timeout period is five minutes. That is, if you do not perform any
operation on the WebUI within five minutes, you are logged out of the WebUI of the
system automatically. In this case, you need to enter the user name and password to log
in again.
l The system locks a user if the user fails to enter a correct password for consecutive five
times. The user is automatically unlocked five minutes later, and the administrator user
can unlock the user in command line.
l To ensure system security, change the initial password after the first login, and then
change your password periodically.
FusionServer G5500 Server
User Guide
5 Configuring the G5500
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
102
