Table 6-1 Memory configuration parameters for Broadwell-EP CPUs
Item Value
Rank Dual rank Quad rank
Rated frequency (MHz) 2400 2400
Rated voltage (V) 1.2 1.2
Operating voltage (V) 1.2 1.2
Maximum number of DIMMs
a
24 24
Maximum capacity per DIMM (GB) 32 64
Maximum memory capacity (GB) 768 1536
Maximum memory capacity at the
maximum operating speed (GB)
512 1024
Maximum operating
frequency (MHz)
One DIMM per
channel
2400 2400
Two DIMMs per
channel
2400 2400
Three DIMMs per
channel
1600 1866
a: The maximum number of DIMMs in this table is based on two-processor configuration.
Note: This table is for reference only. For details about the components that can be
purchased, consult your local Huawei sales representatives.
6.2.3.2 Memory Subsystem Architecture
The G560 provides 24 DDR4 DIMM slots. Each CPU integrates four memory channels. The
four memory channels for CPU 1 are 1A, 1B, 1C, and 1D, and those for CPU 2 are 2A, 2B,
2C, and 2D. Table 6-2 lists channels for each CPU.
Table 6-2 Channels
CPU Socket
Channel DIMM
CPU 1 1A DIMM000(1A1)
DIMM001(1A2)
DIMM002(1A3)
1B DIMM010(1B1)
DIMM011(1B2)
DIMM012(1B3)
FusionServer G5500 Server
User Guide
6 Optional Part Installation
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
125

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
