6.1 Precautions
If multiple components are to be installed, read the installation procedure of each component
before the installation.
CAUTION
Wait until overheating devices have cooled down before touching them to avoid injury.
NOTICE
Properly ground the server before installation to avoid damage to electronic components from
electrostatic discharge.
For details about product specifications, see the server white paper.
To check server compatibility, use the Server Compatibility Checker.
6.2 G560 Optional Part Installation
6.2.1 Hard Disk
Installing a SAS/SATA hard disk
The G560 supports a maximum of two 2.5-inch SAS/SATA hard disks and six 2.5-inch
NVMe SSDs.
NOTE
You do not need to power off the G560 before installing a hard disk.
Step 1 Determine the location for installing the hard disk. Figure 6-1 shows the locations of SAS/
SATA hard disks and NVMe SSDs.
FusionServer G5500 Server
User Guide
6 Optional Part Installation
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
122

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
