No. Item Description
13 DIMM The mainboard provides 24 slots for installing DDR4
DIMMs (12 DIMMs for each processor).
l Maximum memory speed: 2666 MHz
l Memory protection technology for reliability,
availability, serviceability (RAS): error checking and
correcting (ECC), memory mirroring, and memory
sparing
l RDIMMs and LRDIMMs are supported.
Table 11-4 GP316 specifications
No.
Item Specifications
1 Riser card tray Each riser card tray houses one riser card and a maximum of
four half-height half-length single-width PCIe cards. The
GP316 has four riser card trays.
2 PCIe board The PCIe board is configured with two PCIe switches. It
can house four riser cards and one full-height full-length
single-width PCIe card connecting to the G530 V2 through
the chassis backplane.
3 PCIe switch Two PCIe switches on the PCIe board provide 16 PCIe 3.0
x8 slots, connecting to four riser cards.
4 Half-height half-
length single-width
PCIe card
Installed in a riser card tray. Each riser card tray supports up
to four half-height half-length single-width PCIe cards.
5 Riser card A riser card houses half-height half-length single-width
PCIe cards by providing four PCIe x16 connectors. Each
connector provides x8 bandwidth.
11.2 PSU Specifications
The G5500 provides four slots for installing PSUs. Table 11-5 describes the PSUs and power.
FusionServer G5500 Server
User Guide
11 Specifications
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
188
