Huawei FusionServer G5500 User Manual

– On the iBMC WebUI, the LDAP function has been enabled, a user domain has been
set, and the LDAP users who belong to the user domain have also been set. For
details, see the LDAP Settings page.
a. Select the UI language.
b. Enter the LDAP user name and password.
NOTE
To log in as an LDAP user, the user name can be in either of the following formats:
n LDAP user name (Domain is Automatic matching or a specified domain.)
n
LDAP user name@domain name (Domain must be Automatic matching.)
c. Select the LDAP user Domain from the Domain drop-down list.
NOTE
The Domain drop-down list contains the following options:
n
This iBMC: You can select this option to log in as a local user. The system
automatically uses a corresponding user from the local user list.
n
Configured domain servers: You can select a domain server to log in as an LDAP user.
The system automatically uses a corresponding user from the domain server.
n
Automatic matching: If the option is selected, the system searches the local user list
first. If a corresponding user is not found, the system searches the domain servers in
the sequence displayed in the Domain drop-down list.
d. Click Log In.
If the login is successful, the Information Summary page is displayed, showing
the user name in the upper right corner.
----End
5.5.2 Configuring the iBMC
This topic describes how to change the default password of the iBMC and set its IP address.
Scenarios
Change the default iBMC password of the G530 V2 and set its IP address to improve system
security.
NOTE
l The password complexity check function is enabled by default.
l A simple password is easy to crack, which makes the system vulnerable. You are advised to use a
password that meets complexity requirements or to enable the password complexity check function.
l To ensure system security, change your initial password at your first login and change the password
periodically.
Impact on the System
This operation has no adverse impact on the system.
Prerequisites
Conditions
l The G530 V2 is powered on.
FusionServer G5500 Server
User Guide
5 Configuring the G5500
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
106

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
