Huawei FusionServer G5500 User Manual

Table 11-5 PSU specifications
PSU Type Input Parameter Maximum Output
Power
Power Cable
2200 W PSU
l 200 V AC to 240
V AC at 50 Hz
or 60 Hz
l 240 V DC
l One PSU: 2200
W
l Four PSUs in
2+2 redundancy
mode: 4400 W
l Two PSUs in
1+1 redundancy
mode: 2200 W
16 A power cables
complying with
IEC320 C19 and
IEC320 C20
100 V AC to 120 V
AC at 50 Hz to 60
Hz
l One PSU: 1200
W
l Four PSUs in
2+2 redundancy
mode: 2400 W
l Two PSUs in
1+1 redundancy
mode: 1200 W
11.3 Environmental Specifications
Table 11-6 describes the specifications of the G5500
Table 11-6 Environmental specifications
Item
Specifications
Temperature
l Operating temperature: 5°C to 35°C (41°F to 95°F)
l Storage temperature: -40°C to +65°C (-40°F to +149°F)
l Temperature change rate: < 20°C/h (36°F/h)
Humidity (non-
condensing)
l Operating humidity: 5% RH to 85% RH
l Storage humidity: 5% RH to 95% RH
l Long-term storage humidity: 30% RH to 69% RH
Altitude ≤ 3048 m (9999.88 ft). When the altitude is higher than 900 m (2952.8
ft), the highest operating temperature decreases by 1°C (1.8°F) as the
altitude increases by 300 m (984.24 ft). HDDs are not supported at an
altitude of over 3000 m (9842.5 ft).
FusionServer G5500 Server
User Guide
11 Specifications
Issue 02 (2017-12-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
189

Huawei FusionServer G5500 Specifications

General

Chassis type	Rack (4U)
Device class	-
Product color	Black
Number of fans	6 fan(s)
Redundant fans support	Yes
AC input voltage	110-240 V
80 PLUS certification	80 PLUS Platinum
Number of power supply units	4
Power supply unit (PSU) capacity	2200 W
Storage drive capacity	- GB
Storage drives installed	No
Maximum supported storage capacity	- TB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	790 mm
Width	447 mm
Height	175 mm
