Huawei RH2288H V3 User Manual

3.6.2 Removing the Server and Adjustable Guide Rail
Step 1 Wear an ESD wrist strap or ESD gloves. For details, see 1 Safety Instructions.
Step 2 Power o the server. For details, see 4 Powering On and O the Server.
Step 3 Disconnect all power cables and signal cables from the server.
NO TE
Remove power cables rst to prevent damage or injury caused by static electricity.
Step 4 Remove the server.
1. Loosen the captive screws on the server panel using a screwdriver. See (1) in
Figure 3-29.
Figure 3-29 Removing the server
2. Pull out the server along the guide rails away from the cabinet. See (2) in
Figure 3-29.
3. Place the removed server on an ESD platform.
Step 5 Loosen the four screws on the guide rail. See (1) in Figure 3-30.
Step 6 Shorten the guide rail and take it out. See (2) in Figure 3-30.
RH2288H V3 Server
User Guide 3 Installing and Removing the RH2288H V3
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 110

Huawei RH2288H V3 Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4 series
Memory	Up to 1.5 TB, 24 DDR4 DIMM slots
Storage	Supports up to 12 x 3.5-inch or 25 x 2.5-inch SAS/SATA HDDs/SSDs
RAID Support	RAID 0, 1, 10, 5, 50
Network	2 or 4 x GE ports
Power Supply	2 x hot-swappable PSUs
Management	iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
