Huawei RH2288H V3 User Manual

Figure 7-6 Locking the front bezel
----End
7.5 Removing a Drive
Remove a drive before replacing it with a new one.
You do not need to power o the server when removing a drive. If services are
running on the RH2288H V3, back up the data stored on the drive.
Before removing a drive, determine its location to prevent misoperations.
Otherwise, the RAID array will fail.
NO TE
If a drive is frequently removed and installed at an interval of shorter than 30 seconds,
there are risks that the drive cannot be detected.
Table 7-1 shows the mapping between the silkscreens of the drives and slot IDs in
the System Event Log (SEL).
Table 7-1 Mapping
Drive Position
Panel Silkscreen Slot ID in SEL
Front drives 0 to 7 (8 x 2.5-inch
drives)
disk0 to disk7
0 to 7 (8 x 3.5-inch
drives)
disk0 to disk7
RH2288H V3 Server
User Guide 7 Replacing Parts
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 154

Huawei RH2288H V3 Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4 series
Memory	Up to 1.5 TB, 24 DDR4 DIMM slots
Storage	Supports up to 12 x 3.5-inch or 25 x 2.5-inch SAS/SATA HDDs/SSDs
RAID Support	RAID 0, 1, 10, 5, 50
Network	2 or 4 x GE ports
Power Supply	2 x hot-swappable PSUs
Management	iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
