Step 15 Place the removed DVD drive in an ESD bag.
----End
7.26 Installing the DVD Drive
Install a DVD drive to replace the original one.
With Eight 2.5-inch Hard Disks
Step 1 Wear an ESD wrist strap. For details, see 1 Safety Instructions.
Step 2 Remove the DVD drive to be replaced. For details, see 7.25 Removing the DVD
Drive.
Step 3 Take the spare DVD drive out of its ESD bag.
Step 4 Tighten two M2
at-head screws using the Phillips screwdriver to secure the
plastic latch to the DVD drive. See step (1) in Figure 7-52.
Figure 7-52 Installing the DVD drive on a server with eight 2.5-inch hard disks
Step 5 Insert the DVD drive into the support. See step (2) in Figure 7-52.
RH2288H V3 Server
User Guide 7 Replacing Parts
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 194

Huawei RH2288H V3 Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4 series
Memory	Up to 1.5 TB, 24 DDR4 DIMM slots
Storage	Supports up to 12 x 3.5-inch or 25 x 2.5-inch SAS/SATA HDDs/SSDs
RAID Support	RAID 0, 1, 10, 5, 50
Network	2 or 4 x GE ports
Power Supply	2 x hot-swappable PSUs
Management	iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
