Item Specications
Security ● Power-on password
● Administrator password
● TPM
● Chassis-opening logging
● Front bezel (optional)
The front bezel is installed on the front panel and comes
with a security lock to prevent unauthorized operations on
drives.
GPU Integrates the SM750 display chip and provides 32 MB
display memory. The maximum resolution is 1920 pixels x
1200 pixels at 60 Hz with 16 M colors.
NOTE
● After a dedicated graphics card driver is installed, only Windows
Server 2012, Windows Server 2012 R2, Windows Server 2016 can
support the resolution of 1920 pixels x 1200 pixels while other
OSs only support the maximum resolution supported by the built-
in drivers.
● If the resolution is greater than 1024 x 768, the display
eect
may be aected.
2.12 Physical and Environmental Specications
Table 2-15 describes the physical and environmental specications of the
RH2288H V3.
Table 2-15 Physical and environmental
specications
Item
Specications
Dimensions (H x
W x D)
● Chassis equipped with 3.5-inch drives: 86.1 mm (2U) x
447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.)
● Chassis equipped with 2.5-inch drives: 86.1 mm (2U) x
447 mm x 708 mm (3.39 in. x 17.60 in. x 27.87 in.)
RH2288H V3 Server
User Guide 2 Overview
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 75

Huawei RH2288H V3 Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4 series
Memory	Up to 1.5 TB, 24 DDR4 DIMM slots
Storage	Supports up to 12 x 3.5-inch or 25 x 2.5-inch SAS/SATA HDDs/SSDs
RAID Support	RAID 0, 1, 10, 5, 50
Network	2 or 4 x GE ports
Power Supply	2 x hot-swappable PSUs
Management	iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
