QVM6800+ Installation and Operation Manual 10
Chapter 2: Installation
Cable Requirements
DVI Cables
When you connect a QVM6800+ and/or a QVM6800+ C module to the output display module
using the DVI cable, observe the following:
• Do not use a cable that is greater than 10 m long.
• If you must add length to your cable, use an extender that has its own power source. Do not
draw power from the DVI power pin.
Video Input Cables
Use high-quality video cables for the video inputs. Do not exceed the recommended cable
lengths (see Chapter 5: “Specifications” on page 49).
Audio Monitoring, GPI I/O and LTC
The stereo audio analog monitoring output and contact closure GPI I/O are all brought out to
the 10 way connector on the rear panel. A source of longitudinal timecode may be connected to
the connector marked LTC on the rear panel to synchronize on-screen clocks.
High quality screened dual-core cable is recommended for both LTC and audio.
For information on cables and connector pinout refer to Appendix 7: “Connectors and Cables”
on page 57. For information on connector types and part numbers see Chapter 5:
“Specifications” on page 49
Installing ZConfigurator
ZConfigurator software is required to configure and operate QVM6800+ and/or QVM6800+ C
modules and must be installed before use.
Installing software
To install the software, insert the ZConfigurator CD into an available CD drive. If the program
does not autorun navigate to the ZConfigurator folder on the CD and run Setup.exe. Obey the
prompts when the program installs. Accept default locations for the installation directory or
enter preferred locations.
The controlling PC will need to be configured when connecting to a multiviewer for the first
time.
Refer to “Connecting to a Module for the First Time” on page 12 for more information.
