QVM6800+ Installation and Operation Manual 48
Chapter 4: Hardware Monitoring
Monitoring LEDs
Each monitoring LED is green when lit, unless specified otherwise.
The PPC LED monitors the communication systems processor and the FPGA LED
monitors the dedicated video/graphics processor.
Switches
The card edge switch labelled S3 is not used at this time.
Module Status LED
The general module status LED, CD8 at the corner of the module monitors a variety of key
systems and lights up if an error is detected. See Figure 4-1 on page 47 for the location of the
LED, and Table 4-2 for a description of the LED colors.
If the card or module status LED, CD8, is flashing red, contact your Customer Service
representative.
Table 4-1. Monitoring LED Indicators
LED On Off
IN 1 Input 1 signal is present Input 1 signal is not present
IN 2 Input 2 signal is present Input 2 signal is not present
IN 3 Input 3 signal is present Input 3 signal is not present
IN 4 Input 4 signal is present Input 4 signal is not present
IN 5 LOOP IN present (QVM6800+ C only) LOOP IN not present (QVM6800+ C only)
ERR FPGA is in error (red, only during
initialization)
PPC PPC is running PPC is not running
3.3V 3.3V power rail present 3.3V power rail not present
Table 4-2. Module Status LED Descriptions
LED Color
Sequence
Meaning
Off There is no power to the module; the module is not operational.
Green There is power to the module; the module is operating properly.
Red There is an alarm condition.
Flashing Red The module has detected a hardware/firmware fault.
Yellow The module is undergoing configuration.
