QVM6800+ Installation and Operation Manual 49
Chapter 5
Specifications
Overview
The following specification tables appear in this chapter:
Inputs
• “Auto-Sensing Video Inputs” on page 50
• “GPI Inputs” on page 50
• “LTC Input” on page 50
• “LTC Input” on page 50
Outputs
• “DVI-D” on page 51
• “Audio” on page 52
• “GPI Output” on page 52
• “HD-SDI/3G Output” on page 51
Miscellaneous
• “UMD Protocols” on page 52
• “Graphics Overlay” on page 52
• “Propagation Delay” on page 53
• “Power Consumption” on page 53
• “Operating Temperature” on page 53
Specifications and designs are subject to change without notice.
