QVM6800+ Installation and Operation Manual 52
Chapter 5: Specifications
Audio
GPI Output
UMD Protocols
Zandar, TSL, Thomson Simple, Image Video
Graphics Overlay
Stylized video window skins
In-picture embedded audio bargraphs - red, green, yellow
16 text & border colors
4 tally lamps - red, green, yellow, blue
Dynamic UMD/tally
2 analog clocks
6 digital clocks
6 up/down timers
Table 5-7. Audio Output Specifications
Item Specification
Number of outputs 1 stereo output
Type Balanced
Connector
Weidmuller # 1748190000 10 position, 2 row mating cable
receptacle. Harris part no: 134-000765Q00.
Note: This connector is shared with GPI I/O
Impedance Lo-Z 50 Ω
Max Output Level +19.2dBu = 0dBFS
Frequency Response ±0.1dB from 20Hz to 20kHz, relative to 1kHz
THD+N >75dBFS
Table 5-8. GPI Output Specifications
Item Specification
Number of outputs 1
Output type
• Open collector with pull-up resistor to +5 VDC
• Maximum sink current of 200 mA
• Will sink up to 200 mA at 0 V
• Fused output with a thermally resetable fuse
Connector
Weidmuller # 1748190000 10 position, 2 row mating cable
receptacle. Harris part no: 134-000765Q00.
Note: This connector is shared with GPI Inputs and Audio Output
